Video processing technology to maximize the benefit of 16-bits

This camera is designed from the start based on 16-bit A/D and matching 16-bit DSP to maximize the benefits of high bit quantization. Especially for the dark areas of the picture, the higher gradation for gamma and other circuits improves the reproduction, providing for more natural color in the shadow areas of the picture.

Newly developed FPGA

Using mass memory type FPGA,45nm design rule, the video signals are digitized with 16-bit A/D conversion to achieve the highest possible picture quality.

Multi-format

The camera supports various HDTV formats of 1080p (59.94/50Hz), 1080i (59.94/50Hz 4:2:2, 4:4:4), 1080i (119.88/100Hz), 1080p (29.97/25Hz) and 720p (59.94/50Hz), achieving flexible picture representation. * 1080i (119.88/100Hz), 1080p (29.97/25Hz) are option. Furthermore, 23.98P format is also available with the model HDK-970AP/ HDK-97AP.

Native support for 23.98P

The camera supports not only 23.98Psf, but also 23.98P in native (HDK-970AP/HDK-97AP)

Camera Operator Assist Functions

There are two types of camera operator assist functions incorporated in the HDK-970A/AP camera head. The viewfinder detail(VF DTL) function allows the camera operator to increase the detail edges to the viewfinder video for easy-focusing. In addition, the Quick EZ Focus (Focus Assist) function is newly incorporated useful tool, providing very distinct enhancement to the viewfinder edge signal to enable the camera operator to make critical focus adjustment.

Lens Aberration Correction function

The Lens Aberration Correction function is newly incorporated for minimizing the blur and colored edges caused mainly by lens chromatic aberration.

Newly developed 2.3 Mega pixel progressive sensors

New 2/3-inch 2.3 Mega pixel 1080 progressive CCDs are employed to support not only the usual 1080i 59.94/50Hz 4:2:2,720p 59.94/50Hz 4:2:2 1.5G formats, but also 3G formats such as 1080p 59.94/50Hz 4:2:2 and 1080i 59.94/50Hz 4:4:4. Furthermore, 1080i(119.88/100Hz), 1080p(29.97/25Hz)are available as an option. The HDK-970AP adds support for the 1080p(23.98Hz) format.

3Gbps high bit-rate video output

The camera supports 3G-SDI 1080p (59.94/50Hz) wide-band video output as a standard feature for higher picture quality. The single and dual link output is available with CCU-970/BS-97 camera control unit/base station supporting 3G-SDI signal.

2 times slo-motion (1080i 119.88/100Hz)

Switchable for live and slo-motion picture with one camera. It is possible to get a slo-motion picture without changing the camera position. (Option)
*The simultaneous output for live and 2 times slo-motion picture is now under development.

Custom Gamma function

Various kinds of gamma curve can be flexibly set by users.

Digital Extender

The HDK-970A/AP features the Digital Extender function that instantly goes up to 4x to enlarge the image at the center of shot without any loss in image sensitivity.

Variable Color Temp. function

The Variable Color Temp. function enables the camera operator to variably control the color temperature from 2,000K to 20,000K for more precise adjustment at ease.
