UHK-X650
4K Upgradeable HD Studio Camera System
Featuring 2/3-inch Global Shutter CMOS sensors and three chip RGB prism optics. The UHK-X650 4K upgradeable HD Studio Camera System makes its debut as the third member of Ikegami’s UNICAM XE camera range, developed with “no compromise” for the HDR, IP, and 4K era.
Newly Developed 2/3-inch Global Shutter CMOS Sensor
A 3-CMOS optical system using a newly developed 2/3-inch CMOS sensor boasts an S/N of 62dB and a sensitivity of F11 (1080/50p) / F10 (1080/59.94p) in HD. The high dynamic range of the sensor produces high-quality images with excellent color reproduction. The CMOS sensor incorporates a global shutter pixel architecture, enabling the camera to capture natural images even under challenging situations. Still frame replay of fast-moving objects is free from geometric distortion. And there are no flash bands when the camera is shooting under strobe lights or flashes from still cameras.
Field Upgradeable
The UHK-X650 can be upgraded in the field for additional functionality as you encounter various needs that arise in the future. Ikegami provides the following perpetual paid-licenses:
- 4K Capturing (2160p 59.94/50)
- HFR Capturing (2x, 3x, and 4x HD)
- 4K HDR/HD SDR Simulcast
- 24p Capturing
HFR Capturing (Option)
With the HFR option, up to 4x speed in HD* is supported. This is effective when shooting fast-moving subjects such as sports.
OVC (Optical Vignetting Correction)
Automatic electronic compensation of F-drop and vignetting.
* with supported lenses
RBF (Remote Back Focus Adjustment)
The Remote Back Focus Adjustment function helps setting accurate back focus even when the camera head is located in an environment where it is hard to reach the back focus adjustment on the lens or difficult to critically see the viewfinder picture.
*with supported lenses
16-axis Color Correction
This function independently adjusts the hue and saturation of specific colors. It permits subjective manipulation of one color without a ecting the other colors in the scene.
HDR (High Dynamic Range)
The gamma setting is selectable and can be customized to create a specific tone. The “HLG“ (Hybrid Log Gamma), which conforms the international standard (ITU-R BT.2100), is pre-installed and enables more neutral image quality with high contrast for a wider dynamic range. This allows for more image information to be retained with greater headroom and color grading.
Optimal Camerawork with Box Lenses
As the VF position can be lowered and close to the optical axis of the zoom lens, the UHK-X650 provides optimal camera operation with box lenses.
Ratings | |||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Imager | 2/3-inch 3-CMOS, Global Shutter | ||||||||||||||||||
Optical System | 2/3-inch R/G/B Prism | ||||||||||||||||||
Lens Mount | B4 | ||||||||||||||||||
Effective Resolution | H 1920 x V 1080 | ||||||||||||||||||
Motorized Optical Filter |
|
||||||||||||||||||
Ambient Temperature | Operation: -20 to +45 °C (-4 to +113 °F) Storage: -30 to +60 °C (-22 to +140 °F) |
||||||||||||||||||
Operation Humidity | 30 to 90 % *Non-condensation | ||||||||||||||||||
Dimensions (Excluding protrusion) |
W 315 x H 328.5 x D 398 mm (W 12.4 x H 12.9 x D 15.7 inches) |
||||||||||||||||||
Weight | Approx. 19 kg (41.9lbs) without Viewfinder |
Performance | |
---|---|
Item | Specifications |
S/N Ratio | HD: 62 dB or better |
Limiting Resolution (Center, 5% Modulation) |
HD: more than 1000 TVL |
Sensitivity (at 2000 lux, 89.9% reflex) |
F10 (59.94p), F11 (50p) |
Gamma Curves | OFF, 0.35, 0.4, 0.45, HLG, CUSTOM 1 to 5 |
