19-inch Medical Grade LCD-Monitor

MLW-1912C

19-inch Medical Grade LCD-Monitor

Discontinued Product

MLW-1912C is a wide screen 19-inch LCD monitor with the high resolution 1920(H) x 1024(V) LCD panel, 16.7 Million colour graduation (8-bit x 3-Colour), maximum intensity of 330cd/m2 and wide angle of 178 degrees. The Jaggy-less IP conversion and Ikegami unique circuit enable to display more natural images. High performance with HD quality is provided for medical specialists and experts. HD signal input with RGB/Component available.

10-bit signal input

10-bit signal input is built-in MLM-1912C.

10-bit signal process engine

10-bit signal processing based on Ikegami image processing technology allows the smooth gradation of colour.

Jaggy-less I/P conversion process

Ikegami unique Jaggy-less I/P conversion process enables the smooth and clear lines on the display.

178 degrees high contrast viewing angle

LCD panel based on IPS technology is employed for 178 degrees high contrast viewing on UP/DOWN/LEFT/RIGHT. This characteristic prevents from intensity and colour shift by the viewing angle.

Applicable Various Input Signal

Applicable to HD signal (RGB, Component), NTSC/PAL signal (Composite, Y/C) and PC signal input (Analog RGB, Digital DVI-D). SD/HD-SDI signal input is available too.

Various Gamma Characteristics

Variety of Gamma setting can be set, including the Standard CRT Gamma of 2.2 and the DICOM Gamma.

Hue and Chroma setting for all kind of input signal

Colour can be adjusted flexibly for user’s favorite by Hue and Chroma.

Anti-Refection hard coat Screen

Anti-Reflection hard coat screen is installed as standard to reduce the effect of the reflection and to protect the LCD panel.

Save the Power Function

The chosen signal is not input for more than 30 seconds, the monitor automatically can turn OFF to save the power. The function can set ON/OFF.

User memory

Maximum four (4) settings can be set as preset. The parameter such as colour temperature, hue, chroma, gamma, R/G/B gain and display mode can be saved for each user or application.

Maximum 30 meters length of DVI-D cable available

Signal compensation function is installed and the signal degradation is prevented. Then, maximum 30 meters length of DVI-D cable can be used with the monitor.

LED Backlight Panel

By utilizing an energy-efficient LED backlight,the monitor achieves to reduce power consumption.

VESA mount available

A variety of installation brackets for arms and walls can be chosen with the combination of VESA mount.

LCD Panel
Panel Size	19-inch
Pixels	1280 x 1024
Display Size	376 x 301 mm
Aspect Ratio	５：４
Colour Gradient	8-bit x 3 (16.7M)
View Angle	178°/ 178°(Typical)

Input Signal
SDTV	Analog : VBS x 1ch Y/C x 1ch RGB or Y/Pb/Pr x 1ch Digital : Multi-SDI x 1ch (Option)
HDTV	Analog : RGB or Y/Pb/Pr x 1ch Digital : Multi-SDI x 1ch (Option)
PC	DVI : DVI-D x 1ch RGB Analog : HD15P D-Sub x 1ch Supported Resolution : VGA to WUXGA

General
Remote Terminal	Parallel/Serial
Resolutions (TVL)	1000 TV Line or more (at component input)
Maximum Brightness	330cd/m2
Contrast Ration	800:1 (Typical)
Safety Approval	UL60601-1, CSA C22.2No.601.1
EMC Approval	FCC Class A, VCCI Class A
Power Requirement	AC100V to AC120V, AC200V to AC240V
Power Consumption	35W Max
Operation	Temperature: 5 to 35°C Humidity: 30 to 80% (non condensing)
Storage	Temperature : -20 to 60°C Humidity : 30 to 90% (non condensing)
Dimensions	W430 x H389 x D97mm (excluding stand and protrusions)
Weight	5.0kg or less (excluding stand)
Accessories	AC Power Cable, Manual
