MLW-2750UHD

27-inch Medical Grade 4K UHD Color Monitor

The superior detailed picture quality of the Ikegami surgical monitor meets operating room requirements. With its 27-inch IPS 8 megapixel display, the Ikegami’s surgical monitor improves work efficiency both by enabling detailed observation and for multiple imaging applications.

PRESET FUNCTION WITH IKEGAMI MEDICAL GRADE CAMERAS

The Ikegami MLW-2750UHD has a user preset function allowing easy adjustment and storage of the display mode and image setup parameters. It is ideal for use with the MKC-750UHD 4K camera and for Ikegami MKC Full HD cameras.

PICTURE ENHANCEMENT FUNCTION

Ikegami MLW-2750UHD also has a Picture Enhancement Function delivering wide dynamic range reproduction of the video. This function ensures that high quality display extends both to dark and bright areas of the image.

4K HDMI 2.0, DISPLAYPORT 1.2 AND VARIOUS INTERFACE OPTIONS

The MLW-2750UHD is fully compatible with HDMI 2.0 and DisplayPort (Ver.1.2} for UHD resolution (3840 x 2160} at 50/60Hz refresh rate. HD resolution 3G-SDI and DVI-D are also supported.

OUTSTANDING PICTURE QUALITY

The MLW-2750UHD is fitted with an 800cd/m2 high brightness IPS panel. The IPS display also provides accurate reproduction to achieve smooth image graduation well into the deep red section of the colour spectrum.

PICTURE OPTIMISATION FUNCTION

Auto brightness/contrast stabilisation functions are included to ensure the most accurate and consistent shading possible for medical imaging. Gamma options and DICOM PART 14 can also be selected when required.

EASY TO USE

Weighing only 7.7kg (17lb}, the MLW-2750UHD offers the portability required for use in applications such as medical transport carts. Its IP35 rated (front} and IP32 rated (back} panels, give protection against dust and water during operations and post-operation cleaning.

Size	27" class (27.0" diagonal)
Panel Type	IPS
Color Gamut (CIE1931)	sRGB 115%
Colour Depth (Number of Colors)	10bit color (1.07B)
Aspect Ratio	16:9
Resolution	3840 x 2160
Brightness (Typ.)	800 cd/m2
Contrast Ratio (Original)	1000:1
Response Time_Typ. (on/off)	14ms (Typ)
Viewing Angle (CR>10)	178 / 178 degrees
Surface Treatment	With Optical Bonding Glass (1.3T, Anti-Reflection, Anti-Finger)
Singnal
4K	INPUT: DisplayPort (1.2) x1, HDMI (2.0) x1 OUTPUT: DisplayPort (1.2) x1
HD/PC	INPUT: 3G SDI x1, DVI-D x1 OUTPUT : 3G SDI x1, DVI-D x1
USB	For service only
Others	RS-232C
Cable Cover (Rear)	Available
POWER
Input	100-240V, 50/60Hz
Power Consumption	120W
MULTIPLE SCREEN DISPLAY
PIP	Available
PBP	Available
Regulation
Safety	FD(Front) IP35, (Rear) IP32A, MDD, Medical UL, cUL, CE, KC
Water, Dust Proof	(Front) IP35, (Rear) IP32
Others
Weight	7.7kg (17 lb)
Dimensions	654.4 x 410.9 x 58 mm
Motor Fan	Fanless
Standard Accessory	Instruction manual, Power cable (2pcs), AC/DC adaptor, DisplayPort cable, HDMI cable
